| Dust Shield Included | No |
| Travel Length | 3.46 |
| Body Diameter | 1.75 |
| Gas Charged | Yes |
| Dust Shield | No |
| Compressed Length | 304.3 |
| Extended Length | 392.2 |
| Extended Hydraulic Lockout | No |
| Extended Bumper Stop | Yes |
| Compressed Bumper Stop | Yes |
| Parts Pack(s) | P01614 |
| Heavy Duty Supplier | Yes |
| Parts Pack | P01614 |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | End of Shoulder |
| Reserve Tube Diameter | 1.75 |
| Upper Mounting Description | Stem Mount - Stem Length 3.030" - 1/2" X 13 Thread Pitch |
| Lower Mounting Description | Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 1.750" Sleeve OAL |
| Lower Mounting Type | Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 1.750" Sleeve OAL |
| Upper Mounting Type | Stem Mount - Stem Length 3.030" - 1/2" X 13 Thread Pitch |
| Upper Mount Code | S5 |
| Lower Mount Code | LS40 |
| Upper Mount Type | Stem Mount - Stem Length 3.030" - 1/2" X 13 Thread Pitch |
| Part Description | Shock Absorber |
| Internal Rebound Bumper | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.750" Sleeve OAL |
| Part Terminology | Suspension Shock Absorber |
